✓ In Stock | Free Sample Available - test before bulk order | Volume & Tender Pricing - contact sales@topnetsystem.com
| Connector A | MTP/APC Male | Connector B | MTP/APC Female |
| Fiber Mode | SM | Wavelength | 1310/1550nm |
| Fiber Type 1 | G.657.A2 (Compatible with ITU-G657) | Fiber Type 2 | G.657.A2 (Compatible with ITU-G657) |
| Fiber Count | 2*24F | Min. Bend Radius | 7.5mm |
| Polarity | Type C | Cable Jacket | LSZH |
| Cable OD | 3.0mm | Cable Structure | 250um Bare Fiber |
| Return Loss | 60dB | Breakout Tube | 3.0mm |
| Attenuation @1310nm | 0.40dB/km | Insertion Loss | 0.75dB max (SM STD) |
| Storage Temperature | -40 to +75 C | Attenuation @1550nm | 0.30dB/km |
| Installation Tensile Strength | 80/150N | Operating Temperature | -10 to +60 C |
| Connector Durability | 50 times | Cable Tensile Strength (Long/Short) | 80/150N |
