Technical item

Details

PON Interface

1 G/EPON port (EPON PX20+ and GPON Class B+ )

Receiving sensitivity ≤ -27dBm

Transmitting optical power:0 ~ + 4dBm

Transmission distance 20KM

Wavelength

TX:  1310nm, RX: 1490nm

Optical Interface

SC/PC Connector

POTS interface

2 FXS, RJ11connector

Support: G.711/G.723/G.726/G.729codec Support: T.30/T.38/G.711 Fax mode, DTMF Relay Line testing according toGR-909

LAN Interface

4 x 10/100/1000Mbps Ethernet interfaces.  Full/Half, RJ45connector

Wireless

Compliant with IEEE802.11b/g/n, IEEE802.AC

Operating frequency: 2.400-2.4835GHz/5GHZ

support MIMO,  rate up to300Mbps/867Mbps

2T2R,2 external antenna5dBi

Support:  multiple SSID

Channel: Auto

Modulation type:  DSSS, CCK and OFDM

LED

12, For Status of POWER, LOS, PON, SYS, LAN1-4, WIFI, WPS,  Internet, FXS

Push-Button

3,For Function of Reset, WLAN, WPS

Operating Condition

Temperature:  0℃~+50℃

Humidity: 10%～90% (non-condensing)

Storing Condition

Temperature: -30℃~+60℃

Humidity: 10%~90% (non-condensing)

Power Supply

DC12V/1A

Power Consumption

≤8W

Dimension

195mm×130mm×30mm（L×W×H）

Net Weight

0.35Kg
