16G SFP+ SR 850nm 100m MMF

16G SFP+ SR 850nm 100m MMF

16G SFP+ SR 850nm 100m MMF
Item : TSS-16G-SR
Name Value

Descriptions 16G SFP+ SR
Date Rate 16G
TX VCSEL
RX PIN
Reach 100M
Output Power(dBm) -6~1.2
Sensitivity (dBm) -10.5
Temperature (℃) 0-70
16G SFP+ SR transceivers, according to 16 Gigabit Small Form Factor Pluggable “SFP+” Multi-Sourcing Agreement (MSA) SFF-8431 Rev. 4.1 and SFF-8472 Rev. 11.0, are designed for use in Fibre Channel links up to 14.025Gb/s data rate over multimode fiber.

Product Description

Up to 14.025Gb/s bi-directional data links
Electrical interface specifications per SFF-8431
Management interface specifications per SFF-8432 and SFF-8472
Build-in Dual CDR at 14.025Gb/s and bypass at 4.25Gb/s and 8.5Gb/s
SFP+ MSA package with duplex LC connector
Uncooled 850nm VCSEL Laser
35m on 50/125um MMF
100m on high-bandwidth 50/125um(OM3) MMF
Single +3.3V power supply
Class 1 laser safety certified
Metal enclosure, for lower EMI
Operating case temperature: 0 to 70 °C
RoHS Compliant
