| Connector A | MTP/APC (Female) | Connector B | LC/UPC (simplex) |
| Fiber Mode | OS2 9/125μm | Wavelength | 1310/1550nm |
| Fiber Type | Corning SMF-28 Ultra | Min. Bend Radius | 10mm |
| Fiber Count | 12F | Cable Jacket | Hytrel |
| Cable OD | 0.9mm | Cable Structure | simplex |
| Return Loss | ≥60dB | Insertion Loss | Max. 0.35dB (Typical 0.25dB) |
| Attenuation | ≤0.4dB/km @1310nm | Attenuation | ≤0.3dB/km @1550nm |
| Operating Temp. | -10°C ~ +60°C | Storage Temp. | -40°C ~ +75°C |
