10G XFP LR 1310NM 10KM SMF
10G XFP LR 1310NM 10KM SMF
Item : TSXF-10G-LR
Inquiry
Name Value Descriptions 10G XFP LR Date Rate 10G TX DFB RX PIN Reach 10KM Output Power(dBm) -6.5~0.5 Sensitivity (dBm) -15 Temperature (℃) 0-70
XFP LR is compliant with the 10G Small Form-Factor Pluggable (XFP) Multi-Source Agreement (MSA), supporting data-rate of 10.3125Gbps(10GBASE-LR) or 9.953Gbps 10GBASE-LW), and transmission distance up to 10km on SMF.
Supports 9.95Gb/s to 11.1Gb/s bit rates
Hot-pluggable XFP footprint
Maximum link length of 10km with SMF
1310nm uncooled DFB laser
XFP MSA package with duplex LC connector
No reference clock required
+1.8V,+3.3V Supply Voltage
XFI and lineside loopback Mode Supported
-5ºC to 70ºC Operating Case Temperature
Diagnostic Performance Monitoring of module temperature, Supply Voltages, laser bias current, transmit optical power, and receive optical power
RoHS6 compliant (lead free)
