100G QSFP28 SR4 100M OM4 MMF
100G QSFP28 SR4 100M OM4 MMF
100G QSFP28 SR4 100M OM4 MMF
Item
:
TS-QSFP28-SR4
Inquiry
Name
Value
Descriptions
100G QSFP28 SR4
Date Rate
100G
TX
VCSEL
RX
PIN
Reach
100M
Output Power(dBm)
-8.4~2.4
Sensitivity (dBm)
-10.3
Temperature (℃)
0-70
The QSFP28 full-duplex optical module offers 4 independent transmit and receive channels, each capable of 25Gb/s operation for an aggregate data rate of 100Gb/s on 100 meters of OM4 multi-mode fiber.
Product Description
4 independent full-duplex channels
Up to 28Gb/s data rate per channel
QSFP28 MSA compliant
Up to 100m OM4 MMF transmission
Operating case temperature: 0 to 70OC
Single 3.3V power supply
Maximum power consumption 3.5W
MTP/MPO optical connector
RoHS-6 compliant
